Male Connection Couplings

> > > Male Connection Couplings
Product Picture Male Stud Couplings, inch GE

Straight Male Stud couplings, inch

Thread:

Whitworth thread (inch-thread)
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis i S1 M Item No. Price
6 L (light) 315bar G1/8A 8 14 M12x1,5 PE-GE 6-PL/R1/8 1,17 €
6 L (light) 315bar G1/4A 12 14 M12x1,5 PE-GE 6-PL/R1/4 1,74 €
6 L (light) 315bar G3/8A 12 14 M12x1,5 PE-GE 6-PL/R3/8 2,39 €
8 L (light) 315bar G1/8A 8 17 M14x1,5 PE-GE 8-PL/R1/8 2,46 €
8 L (light) 315bar G1/4A 12 17 M14x1,5 PE-GE 8-PL/R1/4 1,76 €
8 L (light) 315bar G3/8A 12 17 M14x1,5 PE-GE 8-PL/R3/8 2,15 €
8 L (light) 315bar G1/2A 14 17 M14x1,5 PE-GE 8-PL/R1/2 4,66 €
10 L (light) 315bar G1/4A 12 19 M16x1,5 PE-GE10-PL/R1/4 1,64 €
10 L (light) 315bar G3/8A 12 19 M16x1,5 PE-GE10-PL/R3/8 2,12 €
10 L (light) 315bar G1/2A 14 19 M16x1,5 PE-GE10-PL/R1/2 3,44 €
12 L (light) 315bar G1/4A 12 22 M18x1,5 PE-GE12-PL/R1/4 2,29 €
12 L (light) 315bar G3/8A 12 22 M18x1,5 PE-GE12-PL/R3/8 2,13 €
12 L (light) 315bar G1/2A 14 22 M18x1,5 PE-GE12-PL/R1/2 3,18 €
12 L (light) 315bar G3/4A 16 22 M18x1,5 PE-GE12-PL/R3/4 6,54 €
15 L (light) 315bar G3/8A 12 27 M22x1,5 PE-GE15-PL/R3/8 3,63 €
15 L (light) 315bar G1/2A 14 27 M22x1,5 PE-GE15-PL/R1/2 2,98 €
15 L (light) 315bar G3/4A 16 27 M22x1,5 PE-GE15-PL/R3/4 11,19 €
18 L (light) 315bar G3/8A 12 32 M26x1,5 PE-GE18-PL/R3/8 7,93 €
18 L (light) 315bar G1/2A 14 32 M26x1,5 PE-GE18-PL/R1/2 3,77 €
18 L (light) 315bar G3/4A 16 32 M26x1,5 PE-GE18-PL/R3/4 7,11 €
22 L (light) 160bar G1/2A 14 36 M30x2 PE-GE22-PL/R1/2 9,58 €
22 L (light) 160bar G3/4A 16 36 M30x2 PE-GE22-PL/R3/4 5,47 €
28 L (light) 160bar G3/4A 16 41 M36x2 PE-GE28-PL/R3/4 25,33 €
28 L (light) 160bar G1A 18 41 M36x2 PE-GE28-PL/R1 10,07 €
35 L (light) 160bar G1¼A 20 50 M45x2 PE-GE35-PL/R1 1/4 13,49 €
42 L (light) 160bar G1½A 22 60 M52x2 PE-GE42-PL/R1 1/2 17,10 €
6 S (heavy) 630bar G1/4A 12 17 M14x1,5 PE-GE 6-PS/R1/4 1,60 €
8 S (heavy) 630bar G1/4A 12 19 M16x1,5 PE-GE 8-PS/R1/4 1,85 €
8 S (heavy) 630bar G3/8A 12 19 M16x1,5 PE-GE 8-PS/R3/8 4,45 €
10 S (heavy) 630bar G1/4A 12 22 M18x1,5 PE-GE10-PS/R1/4 3,36 €
10 S (heavy) 630bar G3/8A 12 22 M18x1,5 PE-GE10-PS/R3/8 2,35 €
10 S (heavy) 630bar G1/2A 14 22 M18x1,5 PE-GE10-PS/R1/2 3,64 €
12 S (heavy) 630bar G1/4A 12 24 M20x1,5 PE-GE12-PS/R1/4 4,45 €
12 S (heavy) 630bar G3/8A 12 24 M20x1,5 PE-GE12-PS/R3/8 2,53 €
12 S (heavy) 630bar G1/2A 14 24 M20x1,5 PE-GE12-PS/R1/2 3,05 €
14 S (heavy) 630bar G1/2A 14 27 M22x1,5 PE-GE14-PS/R1/2 4,44 €
16 S (heavy) 400bar G3/8A 12 30 M24x1,5 PE-GE16-PS/R3/8 8,78 €
16 S (heavy) 400bar G1/2A 14 30 M24x1,5 PE-GE16-PS/R1/2 4,21 €
16 S (heavy) 400bar G3/4A 16 30 M24x1,5 PE-GE16-PS/R3/4 7,05 €
20 S (heavy) 400bar G1/2A 14 36 M30x2 PE-GE20-PS/R1/2 10,93 €
20 S (heavy) 400bar G3/4A 16 36 M30x2 PE-GE20-PS/R3/4 6,27 €
25 S (heavy) 400bar G3/4A 16 46 M36x2 PE-GE25-PS/R3/4 16,70 €
25 S (heavy) 400bar G1A 18 46 M36x2 PE-GE25-PS/R1 10,92 €
30 S (heavy) 400bar G1A 18 50 M42x2 PE-GE30-PS/R1 20,81 €
30 S (heavy) 400bar G1¼A 20 50 M42x2 PE-GE30-PS/R1 1/4 16,02 €
38 S (heavy) 315bar G1½A 22 60 M52x2 PE-GE38-PS/R1 1/2 19,86 €
Product Picture Male Stud Couplings, metric

Straight Male Stud Couplings, metric

Thread:

Metric thread
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis i S1 M Item No. Price
6 L (light) 315bar M10x1 8 14 M12x1,5 PE-GE 6-PL/M10x1 1,13 €
8 L (light) 315bar M12x1,5 12 17 M14x1,5 PE-GE 8-PL/M12x1,5 1,37 €
10 L (light) 315bar M14x1,5 12 19 M16x1,5 PE-GE10-PL/M14x1,5 1,64 €
10 L (light) 315bar M16x1,5 12 19 M16x1,5 PE-GE10-PL/M16x1,5 3,21 €
10 L (light) 315bar M18x1,5 12 19 M16x1,5 PE-GE10-PL/M18x1,5 4,14 €
10 L (light) 315bar M22x1,5 14 19 M16x1,5 PE-GE10-PL/M22x1,5 8,42 €
12 L (light) 315bar M14x1,5 12 22 M18x1,5 PE-GE12-PL/M14x1,5 6,14 €
12 L (light) 315bar M16x1,5 12 22 M18x1,5 PE-GE12-PL/M16x1,5 2,13 €
12 L (light) 315bar M18x1,5 12 22 M18x1,5 PE-GE12-PL/M18x1,5 3,92 €
12 L (light) 315bar M22x1,5 14 22 M18x1,5 PE-GE12-PL/M22x1,5 4,45 €
15 L (light) 315bar M16x1,5 12 27 M22x1,5 PE-GE15-PL/M16x1,5 6,60 €
15 L (light) 315bar M18x1,5 12 27 M22x1,5 PE-GE15-PL/M18x1,5 2,55 €
15 L (light) 315bar M22x1,5 14 27 M22x1,5 PE-GE15-PL/M22x1,5 4,78 €
18 L (light) 315bar M18x1,5 12 32 M26x1,5 PE-GE18-PL/M18x1,5 4,23 €
18 L (light) 315bar M22x1,5 14 32 M26x1,5 PE-GE18-PL/M22x1,5 3,78 €
22 L (light) 160bar M22x1,5 14 36 M30x2 PE-GE22-PL/M22x1,5 18,15 €
22 L (light) 160bar M26x1,5 16 36 M30x2 PE-GE22-PL/M26x1,5 11,76 €
28 L (light) 160bar M33x2 18 41 M36x2 PE-GE28-PL/M33x2 9,68 €
35 L (light) 160bar M42x2 20 50 M45x2 PE-GE35-PL/M42x2 15,64 €
42 L (light) 160bar M48x2 22 60 M52x2 PE-GE42-PL/M48x2 19,42 €
6 S (heavy) 630bar M12x1,5 12 17 M14x1,5 PE-GE 6-PS/M12x1,5 1,63 €
8 S (heavy) 630bar M14x1,5 12 19 M16x1,5 PE-GE 8-PS/M14x1,5 1,80 €
10 S (heavy) 630bar M16x1,5 12 22 M18x1,5 PE-GE10-PS/M16x1,5 2,34 €
12 S (heavy) 630bar M18x1,5 12 24 M20x1,5 PE-GE12-PS/M18x1,5 2,53 €
12 S (heavy) 630bar M22x1,5 14 24 M20x1,5 PE-GE12-PS/M22x1,5 16,83 €
14 S (heavy) 630bar M20x1,5 14 27 M22x1,5 PE-GE14-PS/M20x1,5 4,63 €
16 S (heavy) 400bar M18x1,5 12 30 M24x1,5 PE-GE16-PS/M18x1,5 8,39 €
16 S (heavy) 400bar M22x1,5 14 30 M24x1,5 PE-GE16-PS/M22x1,5 4,21 €
20 S (heavy) 400bar M27x2 16 36 M30x2 PE-GE20-PS/M27x2 6,30 €
25 S (heavy) 400bar M33x2 18 46 M36x2 PE-GE25-PS/M33x2 10,82 €
30 S (heavy) 400bar M42x2 20 50 M42x2 PE-GE30-PS/M42x2 16,61 €
38 S (heavy) 315bar M48x2 22 60 M52x2 PE-GE38-PS/M48x2 21,47 €
Product Picture Banjo Elbow coupling, inch Typ WH

Banjo Elbow coupling, inch

Thread:

Whitworth pipe thread (inch-thread)
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
6 L (light) 315bar G1/8A 24 14 M12x1,5 PE-WH 6-PLR 8,96 €
8 L (light) 315bar G1/4A 30 17 M14x1,5 PE-WH 8-PLR 9,35 €
10 L (light) 315bar G1/4A 30 19 M16x1,5 PE-WH10-PLR 9,47 €
10 L (light) 315bar G3/8A 30 19 M16x1,5 PE-WH10-PL/R3/8 12,21 €
12 L (light) 315bar G1/4A 36 22 M18x1,5 PE-WH12-PL/R1/4 14,83 €
12 L (light) 315bar G3/8A 36 22 M18x1,5 PE-WH12-PLR 12,35 €
12 L (light) 315bar G1/2A 45 22 M18x1,5 PE-WH12-PL/R1/2 21,79 €
15 L (light) 315bar G1/2A 45 27 M22x1,5 PE-WH15-PLR 14,26 €
18 L (light) 315bar G1/2A 45 32 M26x1,5 PE-WH18-PLR 19,54 €
22 L (light) 160bar G3/4A 53 36 M30x2 PE-WH22-PLR 30,49 €
28 L (light) 160bar G1A 66 41 M36x2 PE-WH28-PLR 48,43 €
35 L (light) 160bar G1¼A 76 50 M45x2 PE-WH35-PLR 72,62 €
42 L (light) 160bar G1½A 87 60 M52x2 PE-WH42-PLR 97,26 €
6 S (heavy) 630bar G1/4A 30 17 M14x1,5 PE-WH 6-PSR 8,92 €
8 S (heavy) 630bar G1/4A 30 19 M16x1,5 PE-WH 8-PSR 9,28 €
10 S (heavy) 630bar G3/8A 36 22 M18x1,5 PE-WH10-PSR 11,98 €
12 S (heavy) 630bar G3/8A 36 24 M20x1,5 PE-WH12-PSR 13,02 €
14 S (heavy) 630bar G1/2A 45 27 M22x1,5 PE-WH14-PSR 17,04 €
16 S (heavy) 400bar G1/2A 45 30 M24x1,5 PE-WH16-PSR 19,59 €
20 S (heavy) 400bar G3/4A 53 36 M30x2 PE-WH20-PSR 31,80 €
25 S (heavy) 400bar G1A 66 46 M36x2 PE-WH25-PSR 49,41 €
30 S (heavy) 400bar G1¼A 76 50 M42x2 PE-WH30-PSR 75,47 €
38 S (heavy) 315bar G1½A 87 60 M52x2 PE-WH38-PSR 103,26 €
Product Picture Banjo Elbow coupling, metric

Banjo Elbow coupling, metric

Thread:

Metric thread
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
6 L (light) 315bar M10x1 24 14 M12x1,5 PE-WH 6-PLM 8,96 €
8 L (light) 315bar M12x1,5 30 17 M14x1,5 PE-WH 8-PLM 9,35 €
10 L (light) 315bar M14x1,5 30 19 M16x1,5 PE-WH10-PLM 9,47 €
12 L (light) 315bar M16x1,5 36 22 M18x1,5 PE-WH12-PLM 12,35 €
12 L (light) 315bar M18x1,5 40 22 M18x1,5 PE-WH12-PL/M18x1,5 18,37 €
15 L (light) 315bar M18x1,5 40 27 M22x1,5 PE-WH15-PLM 13,40 €
18 L (light) 315bar M22x1,5 45 32 M26x1,5 PE-WH18-PLM 19,48 €
22 L (light) 160bar M26x1,5 53 36 M30x2 PE-WH22-PLM 29,74 €
28 L (light) 160bar M33x2 66 41 M36x2 PE-WH28-PLM 48,41 €
35 L (light) 160bar M42x2 76 50 M45x2 PE-WH35-PLM 73,07 €
42 L (light) 160bar M48x2 87 60 M52x2 PE-WH42-PLM 97,54 €
6 S (heavy) 630bar M12x1,5 30 17 M14x1,5 PE-WH 6-PSM 8,98 €
8 S (heavy) 630bar M14x1,5 30 19 M16x1,5 PE-WH 8-PSM 9,43 €
10 S (heavy) 630bar M16x1,5 36 22 M18x1,5 PE-WH10-PSM 12,38 €
12 S (heavy) 630bar M18x1,5 40 24 M20x1,5 PE-WH12-PSM 13,02 €
14 S (heavy) 630bar M20x1,5 43 27 M22x1,5 PE-WH14-PSM 18,33 €
16 S (heavy) 400bar M22x1,5 45 30 M24x1,5 PE-WH16-PSM 20,38 €
20 S (heavy) 400bar M27x2 53 36 M30x2 PE-WH20-PSM 31,97 €
25 S (heavy) 400bar M33x2 66 46 M36x2 PE-WH25-PSM 49,39 €
30 S (heavy) 400bar M42x2 76 50 M42x2 PE-WH30-PSM 75,90 €
38 S (heavy) 315bar M48x2 87 60 M52x2 PE-WH38-PSM 103,53 €
Product Picture Banjo coupling, inch

Banjo coupling, inch

Thread:

Whitworth pipe thread (inch thread)
Short version with limited Nominal Pressure.
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
6 L (light) 160bar G1/8A 21 14 M12x1,5 PE-SWVE 6-PLR 14,70 €
8 L (light) 160bar G1/4A 27 17 M14x1,5 PE-SWVE 8-PLR 12,69 €
10 L (light) 160bar G1/4A 27 19 M16x1,5 PE-SWVE10-PLR 10,89 €
12 L (light) 160bar G3/8A 32 22 M18x1,5 PE-SWVE12-PLR 12,78 €
15 L (light) 160bar G1/2A 38 27 M22x1,5 PE-SWVE15-PLR 16,17 €
18 L (light) 100bar G1/2A 44 32 M26x1,5 PE-SWVE18-PLR 18,63 €
22 L (light) 100bar G3/4A 49 36 M30x2 PE-SWVE22-PLR 26,57 €
6 S (heavy) 160bar G1/4A 27 17 M14x1,5 PE-SWVE 6-PSR 10,49 €
8 S (heavy) 160bar G1/4A 27 19 M16x1,5 PE-SWVE 8-PSR 14,11 €
10 S (heavy) 160bar G3/8A 32 22 M18x1,5 PE-SWVE10-PSR 13,00 €
12 S (heavy) 160bar G3/8A 37 24 M20x1,5 PE-SWVE12-PSR 13,78 €
16 S (heavy) 100bar G1/2A 44 30 M24x1,5 PE-SWVE16-PSR 19,17 €
20 S (heavy) 100bar G3/4A 49 36 M30x2 PE-SWVE20-PSR 26,91 €
Product Picture Banjo coupling, metric SWVE

Banjo coupling, metric

Thread:

Metric thread.
Short version with limited Nominal Pressure.
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
6 L (light) 160bar M10x1 21 14 M12x1,5 PE-SWVE 6-PLM 8,99 €
8 L (light) 160bar M12x1,5 25 17 M14x1,5 PE-SWVE 8-PLM 10,18 €
10 L (light) 160bar M14x1,5 27 19 M16x1,5 PE-SWVE10-PLM 10,87 €
12 L (light) 160bar M16x1,5 32 22 M18x1,5 PE-SWVE12-PLM 12,73 €
15 L (light) 160bar M18x1,5 38 27 M22x1,5 PE-SWVE15-PLM 14,82 €
18 L (light) 100bar M22x1,5 44 32 M26x1,5 PE-SWVE18-PLM 19,29 €
22 L (light) 100bar M26x1,5 49 36 M30x2 PE-SWVE22-PLM 25,55 €
6 S (heavy) 160bar M12x1,5 25 17 M14x1,5 PE-SWVE 6-PSM 10,19 €
8 S (heavy) 160bar M14x1,5 27 19 M16x1,5 PE-SWVE 8-PSM 11,83 €
10 S (heavy) 160bar M16x1,5 32 22 M18x1,5 PE-SWVE10-PSM 12,99 €
12 S (heavy) 160bar M18x1,5 37 24 M20x1,5 PE-SWVE12-PSM 13,55 €
4 LL (very light) 100bar M 8x1 17 10 M 8x1 PE-SWVE 4-LLM 10,46 €
6 LL (very light) 100bar M10x1 21 12 M10x1 PE-SWVE 6-LLM 10,37 €
Product Picture Banjo coupling, inch Typ TH

Banjo Tee, inch

Thread:

Whitworth pipe thread (inch thread).
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
12 L (light) 315bar G3/8A 36 22 M18x1,5 PE-TH12-PLR 22,63 €
15 L (light) 315bar G1/2A 45 27 M22x1,5 PE-TH15-PLR 30,68 €
12 S (heavy) 400bar G3/8A 36 24 M20x1,5 PE-TH12-PSR 29,26 €
Product Picture Banjo coupling, metric Typ TH

Banjo Tee, metric

Thread:

Metric thread.
(Pipe coupling/Compression coupling DIN2353)

Included in delivery:

Nut and cutting ring are inclusive.

Materials:

Steel, galvanised

Application:

To screw into cylinders, valves or control blocks and so on.
Sealing: metalic via turned sealing edge.
Safety note
Safety note...
Technical Information
Technical In...
Technical Data:
Qty. for Pipe-Diameter Version Nominal Pressure G Hinweis L S1 M Item No. Price
12 L (light) 315bar M16x1,5 36 22 M18x1,5 PE-TH12-PLM 22,28 €
15 L (light) 315bar M18x1,5 40 27 M22x1,5 PE-TH15-PLM 30,41 €
12 S (heavy) 400bar M18x1,5 40 24 M20x1,5 PE-TH12-PSM 28,98 €
© 1998 - 2015 Hytec-Hydraulik OHG. All rights reserved. All prices include 19% German VAT, plus Shipping Costs.
